ENUSER’S MANUAL BR40
CONNECTOR: SUB-D TYPE 9 PINS
• Pin 2: Rx
• Pin 3: Tx
• Pin 5: GND
The data formats for the normal operations of weighing, counting mode and accumulation of total memory will be different.
Examples:
FRAME: WEIGHING MODE
, -/_ k g CR LF
Head 1 Head 2 Weighing date Weighing unit Terminator
FRAME: PIECE COUNTING MODE
P C S : _ P C S CR LF
QTY -QTY UNITS-
NORMAL OUTPUT
GS 12,340kg GS for gross weight, NT for net weight and a unit of weight.
Nº 1 This number increases each time a new value will be stored in the
memory.
Total 12,340kg Total value stored in memory.
<CR> <LF> Includes 2 characters line change.
<CR> <LF>
TO MAKE THE PARTS COUNTING, WILL BE PRINTED ON UNIT WEIGHT AND THE COUNT
GS 12,340kg GS for gross weight, NT for net weight and a unit of weight.
U.W. 123,4g/pcs The average weight per piece counted by the balance.
PCS 100pcs The total number of pieces counted.
<CR> <LF> Includes 2 characters line change.
<CR> <LF>
RETRIEVING THE TOTAL WEIGHT STORED IN THE MEMORY OF ACCUMULATION, THE OUTPUT FORMAT IS:
It shows a line of stars
*************** Includes 2 characters line change
TOTAL
Nº 5
Peso 21,455kg
<CR> <LF>
<CR> <LF>
10. CALIBRATION(Only personal authorized technician JUMPER K1)
• Turn it on again, and during the count from 9 to 0 press the key
.
• The display will show “CAL” for a few seconds. While it shows “CAL”, press the keys
, and In this same sequence to enter
in the calibration section. The display will show “unload”.
• Remove any weight that is placed on the platform. Press the key
.
• The display will show the last calibration weight used. If this weight is correct you can keep pressing the key
. If it is not correct, use
