ENUSER’S MANUAL BR40
MENU SUB-MENU OPTIONS AND DESCRIPTION
P1 ref
Option only
accessible
by removing
JUMPER
inside K2
Azn 0
0.5d
1d 2d 4d
Automatic tracking of zero
0-Auto
P1 4
P1 10 P1 20 P1 0 P1 2
P1 3 Autozero when turns on
0-Range
P2 2
P2 3 P2 4 P2 10 P2 20 P2 50 P2 100
Manual zero
Speed
SPd 7.5
Determines the sample rate of the A/D converter, press the key To select the
speed of the A/D converter, press the key for record.
7.5: 7,5 times per second
15: 15 times per second
30: 30 times per second
60: 60 times per second
Note: we recommend 15 or 30 times per second.
SPd 15
SPd 30
SPd 60
P2 CAL
Option only
accessible
by with k1
Sig r
FROM SINGLE RANGE
Configuration of the decimal point
Deci C 0 C 0.0 C 0.00 C 0.000 C 0.0000
inc Configuration of the step
1 2 5 10 20
50 100 200
Cap 00000 Enter the capacity of the scale
Cal Linear Linear Calibration.
Pressing the ENTER key, it starts the calibration
nonlin Normal calibration
By pressing the ENTER key, calibration is started
Dual 1
DUAL RANGE SETTINGS
Deci Configuration of the decimal point
Inc Div 1 Set the first step
Div 2 Set the second step
Cap Cap 1 Set the first ability to scale
Cap 2 Set the second ability to scale
Cal Linear Linear calibration
nonlin Normal calibration
Dual 2
DUAL RANGE SETTINGS
Deci Configuration of the decimal point
Inc Div 1 Set the first step
Div 2 Set the second step
Cap Cap 1 Set the first ability to scale
Cap 2 Set the second ability to scale
Cal Linear Linear calibration
nonlin Normal calibration
P3 Pro
Count
This display shows xxxxx to indicate internal divisions.
Reset
This parameter r
etrieves the original configuration by default from the factory.
Setgra
Establishes the local gravity
!
!
