ENENUSER’S MANUAL BW
COMMON SPECIFICATIONS
Interface Exit RS.232 optional
Settling Time Usually 2 seconds
Temperature of operation 0 ºC until 40 ºC / 32 ºF until 104 ºF
Supply of current (external) 115 / 230 V ac, 50/60 Hz, 10 watts
Calibration External automatic
Screen Digital screen LCD of 6 digits
Materials of manufacture Plastic ABS, dish of stainless steel
Size of the dish 225 x 300 mm
General dimensions (width x bottom x high) 320 x 340 x 125 mm
Applications Scales for general ends
Functions Weight, counting, percent weighing, check weighing
Other components and specifications Internal battery rechargeable (70 h. Of length approx.)
3. INSTALLATION
3.1 GENERAL INSTALLATION
The scales should be sited in a location that will not degrade the accuracy.
Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents.
Avoid unsuitable tables. The tables or floor must be rigid and not vibrate. Do not place near vibrating machinery.
Avoid uns table power sources. Do not use near large users of electricity such as welding equipment or large motors.
Avoid high humidity that might cause condensation. Avoid direct contact with water.
Do not spray or immerse the scales in water.
Avoid air movement such as from fans or opening doors. Do not place near open windows.
Keep the scales clean.
Do not stack material on the scales when they are not in use.
3.2 INSTALLATION OF BW SERIES
The BW Series comes with a stainless steel platform packed separa tely. Place the platform in the locating holes on the top cover. Do
not press with excessive force as this could damage the load cell inside.
Level the scale by adjusting the four feet. The scale should be adjusted such that the bubble in the spirit level is in the centre of the level
and the scale is supported by all four feet, If the scale rocks readjust the feet.
Attach the mains cable to the connector on the bottom of the scale. The power switch is located on the base near the front of the scale.
!
Perform a weight calibration as instructed in chapters 10 (setup) and 11 (calibration)
