Name
When reading
disc normally
When disc out When disc in
When no
disc in
TROPEN 0
There is about 1 second 3.3V
pulse when at the moment of disc
out
0 0
TRCLOSE 0 0V
There is about 1 second 3.3V pulse
when at the moment of disc out
0
TROUT 3.41V
3.3V 0V 0V 3.3V
3.3V
TRIN 0
0V 3.3V 3.3V 0V
0
OPO 2.61V 2.75V 2.64V 2.61V
ADIN 2.61V 2.76V 2.61V 2.61V
OP+ 1.66V 1.81V 1.27V 1.81V
OP- 1.85V 2.12V 1.47V 2.04V
