BBQ 4 - Parts and Assembly; Parts List and Diagram

NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from:
PARTS LIST
Key
Qty
Description
1 2
42 3
HEAT DIFFUSERS
2
1
43 3
COOKING GRATE
3 1
44 1
SWING AWAY GRATE
4 1
45 1
CLIP, F/ GREASE CUP
5 1
46 1
GREASE CUP
6
2
47 1
TANK THUMBSCREW
7 1
8 1
9 1
10 1
11 1
Not Pictured
12 1
1
HARDWARE PACK
13 1
1
PRODUCT MANUAL, ENGLISH
14 1
1
PRODUCT MANUAL, SPANISH
15 1
16 1
17 2
18 2
19 1
20 1
21 1
22 3
23 1
24 2
25 1
26 1
27 1
28 1
29 4
30 4
31 1
32 1
33 1
Those on your particular grill model. However, the method of assembly remains the same.:
34 1
35 1
36 1
37 1
38 1
39 1
40
1
41 1
146.23770310 • 11
KEY DESCRIPTION QUANTITY PART NUMBER
1 Warming Rack 1 40800109
2 Cooking Grate 2 408D00110
3 Ignitor Wire, Main Burner 1 50300214
4 Side Shelf 2 408D00040
5 Electronic Ignition Module 1 408D00116
6 Control Panel 1 408D00029
7 Gas Valve, Main Burner 4 40800111
8 Manifold, Main Burner 1 408D00037
9 Bezel, Control Knob 4 40800034
10 Control Knob 4 408D00112
11 Regulator 1 408D00115
12 Right Leg Assembly 1 40800079
13 Wheel 2 40800124
14 Axle Rod Space 2 408D00126
15 Hex Nut 3 110011
16 Cotter Pin 10 110050
17 Axle Washer 3 110018
18 Axle Rod 1 408D00125
19 Bottom Shelf 1 40800089
20 Tank Holder 1 40800130
21 Leg Extender, Front 1 40800D126
22 Leg Extender, Rear 1 40800127
23 Hose Retaining Pin 1 40800134
24 Match Holder Bracket 1 40800129
25 Match Holder 1 40800128
26 Left Leg Assembly 1 40800068
27 Tank Baffle 1 408D00090
28 Front Panel 1 408D00087
29 Back Rail 1 40800085
30 Grease Accumulate Tray 1 40800025
31 Grease Cup 1 40800026
32 Grease Cup Clip 1 40800131
33 Firebox 1 408D00007
34 Lid 1 408D00019
35 Silicone Rubber Bumper 4 40700103
36 Bezel, Temperature Gauge 1 40800105
37 Temperature Gauge 1 40800104
38 Heat Diffuser 4 40800023
39 Flame Carry Over Tube 3 40800022
40 Main Burner 4 40700125
41 Rotate Rod, Lid 2 50300207
No pictured
Hardware pack 1 408D00176
Manual 1 408D00148
If you are missing hardware or have
damaged parts after unpacking grill,
call 1-888-287-0735 for replacement.
To order replacement parts after using grill,
call 1-800-4-MY-HOME
®
