BBQ 4 - Leg Extender, Front; Leg Extender, Rear

M6x13 screw 4 pcs
Wheels and Leg Extenders to Cart
□ Turn assembly upside down.
□ Attach bottom shelf to four legs with (4) M6x13 screws.
□ Insert axle rod through wheel, axle rod spacer, two right legs, another axle rod spacer and other wheel.
Attach with (1) Axle washer, nut and hitch pin.
□ Hammer leg extenders into left legs.
Axle Rod Spacers
Axle Washer
Nut
Hitch Pin
Axle Rod Leg Extender, Rear
Leg Extender, Front
146.23770310 • 17
