18 • 146.23770310
Front Panel
□ Stand cart upright.
□ Attach back brace to top of cart with (4) M4x10 screws.
□ Attach front panel to line up with top of cart with (3) M4x10 screws and leave the bottom hole of left front
leg uninstalled.
□ Attach one side of tank baffle on front panel to the bottom hole of left front leg with (1) M4x10 screw; and
other side to bottom shelf with
(
1
)
M4x10 screw.
Back Brace
tank baffle
M4x10 screw 9 pcs
