BBQ 4 - Page 20

20 • 146.23770310
Left & Right Side Shelf
□ Attach left shelf to firebox as follows:
- From inside to outside of firebox with (2) M6x13 screws and (2) M6 compression washers.
- From outside to inside of firebox with (2) M6x13 screws.
□ Repeat above step for the right side shelf.
M6x13 screw 8 pcs
M6 compression washers 4 pcs
