BCB 14000 BTU - Product Assembly Guide; Exhaust Hose Connection

Pull apart part A exhaust hose so the folds
are separated. Insert exhaust hose into the
part B hose adaptor and rotate clockwise to
lock it in place.
Insert the hose adaptor into the exhaust outlet
and turn counterclockwise to lock it in place.
Insert the other end of the exhaust hose into the part C venting adaptor and rotate clockwise to
lock it in place.
PRODUCT ASSEMBLY
1
2
6 |
C
A
B
