A v i o n
®
8928
a s s e m b l y i n s t r u c t i o n s
b d i u s a .c o m c u s t o m e r s e r v i c e @b d i u s a .c o m
Step 4
Install Handles (J) on the doors and drawers
using the M4 x 25mm Screws (I) and the Phillips
Screwdriver (A) supplied.
Step 3
Carefully lay Assembled Cabinet (F) back-
side down. Using one of 4mm Hex Drivers
(B), attach the completed base assembly to
the bottom of the Assembled Cabinet (F) with
1/4”-20 x 2” Machine Screws (E). *Note:
Each of the metal legs has levelers that can be
adjusted from inside the cabinet using one of the
4mm Hex Drivers (B).
M
K
Adjustable shelf pins (pre-installed) may
be repositioned, allowing you to raise or lower
the adjustable shelf to the desired level. Install
Adjustable Shelf (K) inside the left and right
cabinet area. *Note: To place the adjustable shelf
inside the cabinet, the shelf must be tilted side-
ways to clear the door opening.
F
Completed base
assembly
J
I
E x 6
