PART/DESCRIPTION QTY
H15-FILE BAR CLIP 4
H16-LARGE FILE BAR 1
H17-SMALL FILE BAR 2
Letter/A4
Legal
Grooves
For letter files facing sideways, attach (H15) File Bar Clip to both ends of (H16) Large File Bar as shown.
Place the file bar assembly in the notches located on the left and right drawer side panels. For side
facing legal files, skip this step altogether and hang file folders directly on front and back rails.
Letter/A4
For forward facing files, attach (H15) File Bar Clips
to each end of the (H17) Small File Bars. Slide the
bars onto the rails so that the (H15) File Bar Clip
goes into the groove.
For sideways facing files, see below.
ARRANGING YOUR FILES
FINE TUNING
H15
H15
H15
H15
H15
H17
H17
H17
H17
H15
H15
H16
