SEQUEL 6051/52
LIFT DESK
8
Step 9 -Install the glass bumpers.
Install the 2 glass bumpers H8 as shown.
H8 x 2
H5 x 5
C9
2 Person Task
Step 10 - Install the glass panel.
With the help of another person, carefully place the Glass Panel C8 on top of the desk top with the metal pucks
facing down. The stem of the glass pucks should slip into 5 holes. Secure the glass panel in place from below
using 5 Screws H5. Do not over tighten. Place Grommet Cover C9 into the grommet hole.
C8
To Next Page
