BEALE AK140 - LCD DISPLAY

FRONT PANEL
AK140
AK140
AK140
AK140
20. FUNCTION
Enter the Function Menu.
21. MIXER
Adjust the master volume.
22. METRONOME
Turn the metronome on and o.
23. TOUCH
Turn the Touch response on
and o.
1. A.B.C.
2. FADE
3. DUAL
4. LOWER
5. DSP
6. TOUCH
7. SUSTAIN
8. MODULATION
24. VOICE
Enter the Voice Mode.
25. STYLE
Enter the Style Mode.
24+25 DEMO
Pressing the VOICE and STYLE
buttons simultaneously will
start the DEMO playback.
9. CHORD
10.
VOICES/STYLE/DEMO/SONG
11. TEMPO/COUNT
12. BEAT
13. STORE M1–M4/
ONE TOUCH SETTING
14. RECORD
15. NOR/VAR
26. SONG
Enter the Song Mode.
27. +, –, NUMBER KEYS
Select the number or set
parameter value.
16. BASS CLEF
17. TREBLE CLEF
18. USB CABLE
19. LEFT
20. RIGHT
21. LESSON 1/2/3
22. 61–KEY KEYBOARD
20
22
2524
21
27
23
26
LCD DISPLAY
5
AK140
