Beam 7R - Page 11

230W moving head beam light user manual
9 / 14
every time when they go to a certain
point.
Tilt encoding step
value
Positive direction, step value increases,
negative direction, step value
decreases.The same of values are normal
every time when they go to a certain
point.
System Errors Log
If red ERR is on, it means lamp runs error, go into sub-interface
to check the detail.You can press “Clear” button to clear the log.
DMX Channel
value
Go into sub-interface, show the channel value using number and
percent
Error
Descriptions
MT Board Connect Fail
The driver board has no response.The line
connecting the display board and UART
communication lines in driver board., or
there’s something wrong with driver board.
Pan reset fail
Pan photoelectric switch，or Pan motor’s
problem
Tilt reset fail
Tilt photoelectric switch ， or Tilt motor’s
problem
X-axis Hall Error
(Pan Hall error)
Tilt hall error
Y-axis Hall Error
(Tilt Hall error)
Tilt hall error
Motor Colour reset fail
Color Wheel hall, or Color wheel motor’s
problem
Gobo Hall reset fail
(Motor Gobo reset fail)
Gobo Hall，or Motor Gobo’s problem
Motor Focus reset fail
Focusing Hal, or Focusing Motor’s
Problem
Lamp control fail
Lamps on/off fail, lighter or the lamp’s
problem
lamp hours too long, please replace
Total time of lamp on is over the max
value in Advanced setting, to remind the
user to replace the lamp. After replace,
clear the time value of lamp on in
Advanced setting to record from start.
