Beam 7R - Page 13

230W moving head beam light user manual
11 / 14
Detailed numerical
：
channel
Function
Channel value
Effect
1
COLOUR
WHEEL
000-004
005 -009
010 - 014
015 - 019
020 - 024
025 - 029
030 - 034
035 - 039
040 - 044
045 - 049
050 - 054
055 - 059
060 - 064
065 - 069
070 - 074
075 - 079
080 - 084
085 - 089
090 - 094
095 - 099
100 -104
105 -109
110 -114
115 -119
120 -124
125 -129
130 -134
135 -139
140-144
145-149
150 -200
201 - 255
White
White+Color 1
Color 1
Color 1+Color 2
Color 2
Color 2+Color 3
Color 3
Color 3+Color 4
Color 4
Color 4+Color 5
Color 5
Color 5+Color 6
Color 6
Color 6+Color 7
Color 7
Color 7+Color 8
Color 8
Color 8+Color 9
Color 9
Color 9+Color 10
Color 10
Color 10+Color 11
Color 11
Color 11+Color 12
Color 12
Color 12+Color 13
Color 13
Color 13+Color 14
Color 14
Color 14+White
Rotating on clockwise from fast to slow
Rotating on anti-clockwise from slow to
fast
2
STROBE
000-003
004-103
104-107
108-207
208-212
213-251
Close
Strobe from slow to fast
Open → （ Controlled by dimming
channel）
Pulsation Strobe from slow to fast
Open → （ Controlled by dimming
