230W moving head beam light user manual
13 / 14
5
PRISM
INSERTIO
N
000-127
128-255
Prism Excluded
Prism 1 Inserted
6
PRISM
ROTATION
000-127
128-190
191-192
193-255
Prism indexing
Rotating on anti-clockwise from fast to
slow
Stop
Rotating on clockwise from slow to fast
7
EMPTY
8
FROST
000-127
128-255
Frost Excluded
Frost Inserted
9
FOCUS
000-255
Focus moves linearly from far to near
position
10
PAN
000-255
Pan movement/positioning from 0°to
540°
11
PAN FINE
000-255
Fine control of pan movement
12
TILT
000-255
Tilt movement/positioning from 0°to
270°
13
TILT FINE
000-255
Fine control of tilt movement
14
MARCO
FUNCTION
……
……
15
RESET
000-025
026-076
077-127
128-255
Unused range
Effects reset
Pan /Tilt Reset
Reset
16
LAMP
CONTROL
000-009
010-100
101-255
Unused range
Lamp off
Lamp on
EXTENDED CHANNEL
17
PAN-TILT
TIME
000-255
Speed from fast to slow
18
COLOUR
TIME
19
DIMMER-P
RISM-FRO
ST TIME
20
GOBO
TIME
