Beam 7R - Page 9

230W moving head beam light user manual
7 / 14
DMX
Address
1~512
The yellow arrow was selected,Press “OK” button
into Edit Mode,when the font color is red,press “UP
or ”DOWN” to change the address code, Press “OK”
again to save and exit the edit.
Channel
Mode
Standard
16CH
Standard 16 channel mode ， 17~20 channels are
useless
Extended
20CH
Extended 20 channel mode，17~20 channels control
speed（see the channel list）
Pan Invert
OFF
Exchange start and end points when open,The default
is OFF
ON
Tilt Invert
OFF
Exchange start and end points when open,The default
is OFF
ON
Pan-Tilt
Swap
OFF
ON
Invert channels of Pan-Tilt(including fine-tuning)
Pan-Tilt
Encoder
ON
Use encoder (optocoupler)to estimate the wrong step
and right the wrong position
OFF
Don’t use encoder(optocoupler) to right the position
DMX Signal
KEEP
Keep going as this status
CLEAR
Motor return, stop running.
Display
OFF
Always bright
ON
screen saver
Lamp on after
startup
off
Reset after power on, not turn on the lamp(need to
use the Menu or console to turn on lamps manually)
on
Automatically turn on the lamps after power on, and
reset only after turning on the lamps successfully
Linear
Change of
Color Wheel
ON
Linear change of color wheel
OFF
No linear change of color wheel, half color change
Restore
Default
Setting
The Confirmation dialog will show after pressing
“OK” button, press “OK” again to restore the default
setting.
