4. PREPARING YOUR TRANSMITTER
With electric driven models remove the motor from the main gear when performing the basic setup for safety
reason! Additionally deactivate the throttle by using the „Throttle HOLD“ switch, so the motor won‘t start to turn when
moving the thrust stick.
When flying a nitro or gasser heli remove the servo horn from the throttle servo before first power up to prevent
jamming of the servo due to wrong servo setup.
You must not use any mixing functions on the output channels! Especially it is not allowed to use mixing functions for the
swashplate servos. Deactivate all output channels that are not used. In the basic configuration we only need pitch, aileron,
elevator, rudder, throttle and one channel to adjust the tail gyro gain.
Create a new helicopter model memory in your transmitter that supplies different flight modes for controling throttle, pitch
and the tail gyro gain in different flight situations.
Only the pitch channel
must be controled when
moving the thrust stick.
The same applies to aileron,
elevator and rudder.
Each control function must exactly control one output channel. The servo throws must be set to 100% and all trims and sub
trims must be zero. For the basic setup do not change the pitch curves yet. The throttle curves and throttle servo settings can
be adjusted as necessary for this model in case you do not intend to use the internal RPM Governor function of MICROBEAST
PLUS. If you want to use the integrated RPM Governor function also do not touch the throttle settings yet.
