7
OPERATION
Camera
1. Place the camera onto a stable table top or installed on wall but out of reach of baby
(preferably 1m away).
2. Switch on camera by long press of power button 1 , the power indicator 3 will light
up green.
3. Adjust the microphone sensitivity (set on PU side) such that the camera will be
triggered to transmit baby’s voice whenever the microphone 5 picks up a sound at
your desirable loudness level. Once the camera starts to transmit, the transmit
indicator 3 will light up blue. When the baby becomes silent and microphone 5 does
not pick up any sound, the camera will stop transmitting and go into standby mode. At
the same time, transmit indicator 3 will go off. Under such mode, the radiation is
reduced to minimum level.
4. The night light 4 can be set to OFF, ON or VOX (on when detecting sound) using the
PU. The light intensity can be adjusted using + - buttons 8 9 .
5. This camera is incorporated with lullaby function which can be remotely turned on or
off using PU. There are 6 different factory preset song/sound, parents can also
download their preferred music (in MP3 format) to a SD card and insert into the slot 7
for more song selection. The volume of music heard in speaker 10 can be adjusted by
PU.
N.B. insert the SD card only when camera is switched off, otherwise its content
may not be able to be detected by camera.
6. When there is sufficient light intensity, the screen 20 will show a colourful image.
Once the environment getting dark, the IR LED in camera will automatically turn on to
illuminate the surroundings and the screen 20 will show a black white image.
7. Using the buttons 14 15 16 17 on PU, parents can be pan (330º) or tilt
(110º) the camera lens to capture the different view of baby.
8. When baby grows up to become a toddler, parents can activate the motion tracking
function in PU and the camera lens will automatically track the movement of toddle .
