Table of contents
Section 2 INSTALLATION Page
2.1 General 2-1
2.2 Pre-instailation check 2-1
2.2.1 General 2-1
2.2.2 Visual inspection 2-1
2.3 Mechanical installation 2-1
2.3.1 Mechanical installation VHF transceiver 2-1
2.3.2 Mechanical installation of a temperature sensor 2-1
2.4 Installation wiring 2-2
2.4.1 General 2-2
2.4.2 Microphone connection 2-2
2.4.3 Speaker/headphones connection 2-3
2.4.4 IC connection 2-3
2.4.5 Panel lighting 2-3
2.5 Auxiliary audio input (optional) (standard as of module No. 471) 2-4
2.6 Testing after installation 2-8
2.6.1 Ground testing with engine OFF 2-8
2.6.2 Ground testing with engine ON 2-8
Fig. 2-1 Jumpers location for charging the microphone input from dynamic to
standard microphone 2-3
Fig. 2-2 Panel connection 2-4
Fig. 2-3 Auxiliary audio input 2-4
Fig. 2-4 Dimensions of VHF transceiver 2-5
Fig. 2-5 Aircraft wiring 2-6
Fig. 2-6 Wiring diagram AR 3201 - ( ) with Speaker - Junction 2-7
Fig. 2-7 Location of IC control 2-8
AR 3201 - ( )
DV 28110.03/.04 Issue 04/92 2-I
