1.5 Specifications
1.5.1 General data Transceiver
Operating voltage 12,4 V . . . 15,1 V
Emergency operation (10,0 V) Intelligible communication
Current consumption 14 V without
Panel illumination
Receive ,, stand by ‘‘ typ. 70 mA
Receive ,, stand by ‘‘ with auxiliary input typ. 90 mA
Transmit typ. 1 .8 A
Panel illumination 13,8 V / 40 mA DC
Fuse 5A
Operating temperature range D1 - 20° . . .+ 55°C,
Env. Cat. RTCA DO - 160A shorttime temperature + 70°C
Altitude max. D1 50000 ft
Env. Cat. RTCA DO - 160A
Vibration MNO
Env. Cat. RTCA DO - 160A
Dimensions
Panel 60.6 mm x 60.6 mm
Mounting depth 212.5 mm
Weight 0.9 kg
1.5.2 Receiver specifications
Type Receiver Single superhet
Frequency range 118.000 MHz . . . 136.975 MHz
Channels 760
Channel spacing 25 kHz
Sensitivity (mod. 1000 Hz/30%) ≤ 5µV emf for 6 dB S+N
N
Bandwidth ≥ ± 8 kHz at 6 dB down
Selectivity ≥40 dB at ± 17 kHz
≥60 dB at ± 25 kHz
AR 3201 - ( )
DV 28110.03/.04 Issue 04/92 Page 1-5
