Becker AR 3209 - Mode

The CAUTION, WARNING and NOTE highlights have the following
meanings :
Failure to comply, or incorrect compliance,
with these instructions or procedures can lead
to injuries or fatal accidents.
Failure to comply, or incorrect compliance,
with these instructions or procedures can lead
to damage to equipment.
NOTE Feature to which attention should be drawn.
l Never connect the VHF transceiver to alternating current
voltage or to voltage sources exceeding 32 V DC.
l
Never connect the VHF transceiver with reversed polarity
to a voltage source.
l
The installation or use of the VHF transceiver in ambient
temperatures below -20° C or above +55° C is to be
avoided.
l
Switch off the unit when starting or shutting down engines.
Page 4 Issue 10/95
Operating Instructions
WARNING
CAUTION
CAUTION
Technical Data
Power supply voltage AR 3209 - (09)
Nominal supply voltage 13.75 V DC
Supply voltage range 12.4 V to 15.1 V
Emergency operation (10.0 V) Good intercom
Power consumption without panel lighting
“Standby” reception mode £ 70 mA
Reception mode £ 500 mA
Transmission mode £ 2.5 A
Panel lighting 1 A at 5 V DC
400 mA at 13.75 V DC
Power supply voltage AR 3209 - (11)
Nominal supply voltage 13.75 V DC
Supply voltage range 12.4 V to 15.1 V
Emergency operation (10.0 V) Good intercom
or
Nominal supply voltage 27.5 V DC
Supply voltage range 24.8 V to 30.3 V
Emergency operation (20.0 V) Good intercom
Power consumption without panel lighting
“Standby” reception mode £ 70 mA
Reception mode £ 500 mA
Transmission mode £ 2.5 A
Panel lighting 1 A at 5 V DC
400 mA at 13.75 V DC
200 mA at 27.5 V DC
Issue 10/95 Page 29
Becker AR 3209
