Becker Audio 30 Export 3301 - Connector; Connector Block (Board 4040)

CSD - Version: 26/99
BE
3
Circuit diagram - Mercedes Benz MY98
Connector Connector block (Board 4040) 3301Audio 30 DIN Export
A1 A3 A5
A6A2
A7
A8
A4
Fuse 10A
B1 B3 B5
B2 B4 B6
B7
B8
C1 C3 C5 C7
C2 C4 C6 C8
C9
C10
Connector block
Chamber C
Chamber B
Chamber A
C1 C3 C5 C7
C2 C4 C6 C8
C9
C10
B1 B3 B5
B2 B4 B6
B7
B8
A1 A3 A5
A6A2
A7
A8
A4
Chamber CChamber B Chamber A
Loudspeaker
rear right +
not assigned
Speed
dependent Vol.
control
PIN
Chamber A Chamber B Chamber C
1
Loudspeaker
rear right -
not assignedK-line
2
Loudspeaker
front right +
not assigned
Telephone
mute
3
Loudspeaker
front right -
Wake up lineTerminal 30,
Battery
4
Loudspeaker
front left +
Battery 12V
Fuse
Control
output 12V
5
Loudspeaker
front left -
Terminal 31,
Ground
Battery 12V
Fuse
6
Loudspeaker
rear left +
not assignedTerminal 15,
Ignition
7
not assigned
9
not assigned10
Loudspeaker
rear left -
not assignedTerminal 31,
Ground
8
