Assembly and Operating Instructions
Technicaldata
Changingthebatteries
Cleaning
Nominal voltage 230 V AC / 50 Hz
Switched current 5 A /250 V AC FOR cos ϕ=1
Battery type CR 2032
System of protection IP 20
Protection class
(In accordance with the
assembly specications) II
Permissible ambient temperature 0 to +55 °C
Type of installation Concealed: Ø 58 mm wall-mounted
Exposed: in appropriate exposed casing
1. Disconnect the operating device.
2. Remove the battery.
3. Insert the new battery properly.
4. Reset the time.
 Note
Thepre-setvaluesremainstored.
Clean the device with a damp cloth only. Do not use a cleansing agent as doing
so may damage the plastic.
