Deleting both limit positions
Any additional functions that may have been set are deleted at the same time, or are reset
to the factory default settings.
Open/close the shading solution to a point between the limit positions.
Press the programming button and keep it pressed.
Then press down the travel button and keep it pressed.
Now release the programming button, but continue to keep the travel button pressed.
Next press the programming button again.
▻ The tubular drive confirms.
► Both limit positions are deleted.
Automatic adjustment of direction of rotation
After the limit positions have been set, the drive automatically adjusts the direction of rotation, so that the drive always moves UP
when the black wire is energised.
Activating/deactivating the additional fabric untensioning function with the
programming unit
The "to retracted stop" limit position must be set for the fabric untensioning function.
On delivery, the fabric untensioning function is activated. To deactivate it, move to the Retract limit position. Press the program-
ming button for approx. 5seconds. The drive moves a short distance out of the limit position and back again. The fabric untension-
ing function is now deactivated.
Repeat the procedure to activate it.
14
