Becker R20/17 C SE+ K8 User Manual

Technical data dia. 58
Type L60/11
C SE+ K8
L80/11
C SE+ K8
Rated torque [Nm] 60 80
Output speed [rpm] 11
Limit switch range 64revolutions
Supply voltage 230VAC/50Hz
Connected load [W] 265 310
Rated current consumption [A] 1.20 1.40
Operating mode S24min
Degree of protection IP44
Min. tube inside diameter [mm] 60
Emission sound pressure level
[dB(A)]
≤70
What to do if...?
Problem Remedy
Tubular drive overruns the limit position or does not reach the
set limit position.
Repair electrical installation and re-program limit positions.
Check electrical installation; remove external devices; reset
limit positions.
Stops have broken off or one or several attachments are
broken. Repair system; reset tubular drive, then re-program
limit positions.
The tubular drive will not retract after setting the extended limit
position.
Delete the limit positions, reprogram the outer limit position,
and retract immediately.
Tubular drive stops arbitrarily; cannot be restarted in the same
direction.
Use a more powerful tubular drive.
Ensure that the sun protection system runs smoothly.
Delete limit positions, then re-program limit positions.
Tubular drive does not run in the right direction. Tubular drive is overheated. The tubular drive is operational
again after a few minutes.
Tubular drive is faulty (does not work even after standing still for
a long period of time). Replace the tubular drive.
Check the electrical connection.
Tubular drive only runs for approx. 1 second. Tubular drive is faulty. Replace the tubular drive.
When you attempt to set the limit positions using the program-
ming unit, this does not work.
Programming unit faulty. Replace programming unit.
Check the electrical connection.
16
