General
These tubular drives are high-quality products with the following features:
• Optimised for articulated-arm awnings, cassette awnings, drop-arm awnings, screens and conservatory shades.
• Easy to set and delete the limit positions using the programming unit
• Automatic shading solution length adjustment: Changes in the fabric (temperature, ageing, moisture) are accommodated
• Tensile load is optimally adapted to the mechanical requirements of the sun protection system
• Automatic cloth untensioning protects cloth
• Automatic detection of retracted limit position
• Simple to set the extended limit position by pressing a button on the programming unit
• Left or right hand installation
• Several drives can be operated in parallel
• Comprehensive range of the drive manufacturer's control units can be used
• Compatible with existing drives with electronic limit switching (4-core connecting cable)
• For plug-in connecting cable
• Automatic detection of limit positions thanks to intelligent electronic system with stop systems
• The limit positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
• Smooth operation of the system and the drive increases the service life
Please observe these Assembly and Operating Instructions when installing and setting the equipment.
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 24th calendar week in 2012
Ser. No.: 1224XXXXX
Explanation of pictograms
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in injury.
ATTENTION
ATTENTION indicates measures that must be taken to avoid damage to
property.
Denotes user tips and other useful information.
Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu-
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus-
tomer advice.
3
