Beckhoff BK3 0 Series User Manual

Extended functions
BK3xx0 75Version: 4.3.0
Byte Bit Description
15 0,1 Assignment for terminal 1
0: DP DataExchange (default)
2: disabled (Multi-Config mode)
2,3 Assignment for terminal 2
0: DP DataExchange (default)
2: disabled (Multi-Config mode)
4,5 Assignment for terminal 3
0: DP DataExchange (default)
2: disabled (Multi-Config mode)
6,7 Assignment for terminal 4
0: DP DataExchange (default)
2: disabled (Multi-Config mode)
... ... ...
30 6,7 Assignment for terminal 64
0: DP DataExchange (default)
2: disabled (Multi-Config mode)
41 0,1 Assignment for terminal 65
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
... ... ...
56 6,7 Assignment for terminal 128
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
Enabling/disabling via DPV1 Write
The terminals are enabled/disabled through Slot_Number 0 and Index 1 or 2:
Index Byte Bit Description
1 0 0,1 Assignment for terminal 1
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
2,3 Assignment for terminal 2
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
4,5 Assignment for terminal 3
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
6,7 Assignment for terminal 4
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
... ... ...
15 6,7 Assignment for terminal 64
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
2 0 0,1 Assignment for terminal 65
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
... ... ...
15 6,7 Assignment for terminal 128
0: DP-DataExchange (Default)
2: disabled (Multi-Config-Mode)
