2.3 Technical data
Technical data CX8080
Processor 32bit, 400MHz, ARM9
Internal main memory 64 MB RAM (internal, not extendable)
Web-based Management yes
Flash memory MicroSD card (ATP) 512 MB (optionally 1, 2, 4 GB)
Interfaces 1 x USB device (behind the front flap)
1 x RJ45 Ethernet, 10/100 MBit/s (ADS over TCP/IP)
1 x D-sub (1 x RS232, 1 x RS485)
Protocols (serial) any
Interface for I/O terminals K-Bus or E-Bus, automatic recognition
Process data on the K-bus max. 2 KB input data
max. 2 KB output data
Diagnostics LED 1 x power, 1 x TC status, 2 x bus status
Clock internal battery-backed clock (RTC) for time and date
(battery exchangeable)
Control software TwinCAT PLC runtime (from version 2.11 R3)
Operating system Microsoft Windows CE 6.0
Programming TwinCAT PLC
Programming languages IEC 61131-3
Online Change Yes
Up/download code Yes/Yes
Power supply 24 V
DC
(-15 %/+20 %)
UPS 1-second UPS
Power supply for I/O terminals max. 2 A
Max. power loss 3.0 W (including system interfaces)
Dielectric strength 500 V (supply / internal electronics)
Dimensions (W x H x D) 64 mm x 100 mm x 73 mm
Weight approx. 180 g
Permissible ambient temperature during operation 0° C ... +55° C
Permissible ambient temperature during storage -25° C ... +85° C
Correct installation position See chapter Installation positions
Relative humidity 95 % no condensation
Vibration / shock resistance according to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission according to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
System data RS232 (CX8080)
Number of I/O modules 1
Transmission medium screened copper cable, 3 x 0.25 mm²
Cable length 15 m
Data transfer rate 300 baud...115 kbaud
Topology peer to peer
CX8080 11Version: 1.0.0
