Product overview
EK110x, EK15xx 23Version: 3.6
EtherCAT coupler EK1100-0008 (M8 connection)
The EK1100-0008 coupler connects EtherCAT with the EtherCAT Terminals (ELxxxx/ESxxxx). One station
consists of a coupler EK1100-0008, any number of EtherCAT Terminals and a bus end terminal.
The coupler converts the telegrams from Ethernet 100BASE-TX to E-bus signal representation. Compared to
EK1100 the EK1100-0008 has two M8 sockets instead of two RJ45 sockets, compatible to the ones of the
EtherCAT-Boxes.
The upper Ethernet interface is used to connect the coupler to the network; the lower M8 socket serves for
the optional connection of further EtherCAT devices in the same strand.
The coupler supplies the connected terminals with the necessary E-bus current for communication. The
coupler can supply a maximum of 5V/2A. Power feed terminals (e.g. EL9410) must be integrated if more
current is required.
In the EtherCAT network, the EK1100-0008 coupler can be installed anywhere in the Ethernet signal transfer
section (100BASE-TX) except onto the switch directly. By using respective powerful Ethernet cables e.g.
ZK1090-3131-1xxx distances of 100m are also possible via M8.
Quick links
• EtherCAT basics [}31]
• Configuration instructions [}56]
• Diagnostic LEDs [}66]

Beckhoff EK1100 Specifications

General

Product Type	EtherCAT Coupler
Number of Ports	2
Fieldbus	EtherCAT
Bus Interface	EtherCAT
Protection Class	IP20
Max. Current Supply for the E-bus	2 A
Electrical Isolation	500 V (E-bus/Fieldbus)
Weight	approx. 150 g
Relative Humidity	95%, no condensation
Vibration/Shock Resistance	Conforms to EN 60068-2-6/EN 60068-2-27
EMC Immunity/Emission	Conforms to EN 61000-6-2/EN 61000-6-4
Approvals/Markings	CE, UL, ATEX, IECEx
Power Supply	24 V DC (-15%/+20%)
Operating Temperature	-25°C to +60°C
Storage Temperature	-40°C to +85°C
Current Consumption Power Contacts	10 mA
Number of I/O Modules	64
Installation Position	any
