PLC API
TS5055 39Version: 1.3
12.1.3 MC_ReadFlyingSawCharacteristics
MC_ReadFlyingSawCharacteristics
ExecuteBOOL
↔
SlaveReference To AXIS_REF
↔
CamTableCharacReference To MC_FlyingSawCharacValues
BOOLDone
BOOLBusy
BOOLError
UDINTErrorID
The MC_ReadFlyingSawCharacteristics function allows the characteristic figures for the synchronization
phase of the Universal Flying Saw to be read.
Inputs
VAR_INPUT
Execute:BOOL;
END_VAR
Execute A rising edge initiates reading the characteristic values from the TwinCAT NC.
The data calculated is not available until the Universal Flying Saw starts.
Outputs
VAR_OUTPUT
Done: BOOL;
Busy: BOOL;
Error: BOOL;
ErrorID: UDINT;
END_VAR
Done Is set to TRUE when the data record has been successfully read.
Busy The Busy output becomes TRUE when the command is started with Execute and
remains TRUE if the command is processed. When Busy becomes FALSE again, the
function block is ready for a new command. At the same time one of the outputs,
Done or Error, is set.
Error Becomes TRUE, as soon as an error occurs.
ErrorID
Supplies the error number, see Overview of NC errors (TC2).
Inputs/outputs
VAR_IN_OUT
Slave: AXIS_REF;
CamTableCharac: MC_FlyingSawCharacValues;
END_VAR
Slave Axis structure of the slave.
CamTableCharac:
Structure containing the characteristic values [}42].
