Device Overview
Legend
(See fold-out page for illustrations)
1 Water tank lid
2 Temperature lamp
3 Water tank
4 Steam nozzle
5 Main unit
6 Pressing aid
7 Measuring spoon
8 Drip tray
9 Storage plate
10 Por tafi lter
11 Sieve insert
12 Por tafi lter mount
13 Selector switch (Coffee / Off / Steam)
14 On / Off switch
15 Operating lamp
16 Hotplate
a Por tafi lter for capsule insert
b Capsule insert
c Small sieve insert for powder and pads
d Large sieve insert for powder and pads
e Por tafi lter for powder and pad inserts
