Wall mounting
All of our monitors are ready to be fitted with a 75mm or 100mm VESA mount thanks to the four screw points found
on the back of all our monitors and touchscreens.
Wall mount (with VWB1):
1. Remove the monitor’s stand by removing the 4 screws that attach it to the screen.
2. Using the 4 screws you just removed from the monitor, attach the VESA baseplate to the monitor.
3. Next screw the other half of the VESA into the wall you intend to attach the monitor to. Be sure the mount is
right-side up.
4. Once each half of the mount is attached to the monitor and wall, respectively, the mount is completed and ready for
installation. Simply slide the monitors VESA mount into the wall bracket.
Mounting options
02
01
Desktop Installation
All of our monitors come ready to be used on a desktop with an adjustable stand.
The VWB1 wall bracket is optional and not included as standard.
MOUNTING OPTIONS
17 EN
