1 Heating block :

1.1 Operating unit

1.2 Mains switch

1.3 Heating slots for sample vessels

1.4 Aeration slots

1.5 Mains plug

1.6 Mounting rail, with:

1.7 Hooks for suspending the sample rack while not

in use

1.8 Cut-outs for suspending the exhaust collector

while not in use

2 Sample rack

2.1 Handles

2.2 Upper guide roller; it also serves for suspending

the sample rack on the hooks 1.7

2.3 Lower guide roller

2.4 Sample vessels

Overview of the K8 / K12 / K20 / K16 / K24 / K40
