1.11.2
2.5
← 1.3 - 1.8
2.7
2.6
2.8
2.9
4
2.5 Front lid, removable
2.6 Fold for fastening the front lid on the frame of
the sample rack
2.7 Middle part of the frame, to hold the fold (2.6) of
the front lid
2.8 Hooks for fastening the front lid on the lower
frame bar of the sample rack
2.9 Lower bar of the frame, to hold the hooks (2.8)
of the front lid
3 Exhaust collector:
3.1 Handles
3.2 Gas outlet
3.3 Socket for suction hose
3.4 Suction hose
3.5 Hooks for suspending the exhaust collector in
the cut-outs 1.8 on the mounting rail
4 Drip pan
