Installation
The necessary screws are included with the module for mounting
in a Eurorack case. Connect the power cable before mounting.
Depending on the rack case, there may be a series of xed holes
spaced 2 HP apart along the length of the case, or a track that
allows individual threaded plates to slide along the length
of the case. The free-moving threaded plates allow precise
positioning of the module, but each plate should be positioned in
the approximate relation to the mounting holes in your module
before attaching the screws.
Hold the module against the Eurorack rails so that each of the
mounting holes are aligned with a threaded rail or threaded
plate. Attach the screws part way to start, which will allow
small adjustments to the positioning while you get them all
aligned. After the nal position has been established, tighten the
screws down.
Specications
Pulse Width Input
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 70 kΩ, unbalanced
Maximum input level ±10 V, 4% per volt
VCO Output
Type 4 x 3.5 mm TS jacks,
DC coupled
Impedance 1 kΩ, unbalanced
Maximum output level 10 V p-p
Frequency range with no
external CV
10 Hz to 500 Hz
Frequency range using
external CV
1 Hz to 30 kHz
Sync Input
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 100 kΩ, unbalanced
Maximum input level 10 V p-p
Minimum input to trigger 2.5 V p-p
Sync Output
Type 2 x 3.5 mm TS jacks,
DC coupled
Impedance 1 kΩ, unbalanced
Maximum output level 10 V p-p
Control Inputs
Type 6 x 3.5 mm TS jacks,
summed
Impedance 50 kΩ, unbalanced
CV range ±10 V, 1 V/oct
Controls
PW level -∞ to unity gain
PW manual 50% to min
Waveform Triangle, sawtooth, pulse
Range 32', 16', 8', 4', 2'
Pitch ±1 octave
Weak/strong Sync mode select
Mod level -∞ to unity gain
Power
Power supply Eurorack
Current draw 90 mA (+12 V),
70 mA (-12 V)
Physical
Dimensions 81 x 129 x 46 mm
(3.2 x 5.1 x 1.8")
Rack units 16 HP
Weight 0.2 kg (0.44 lbs)
LEGAL DISCLAIMER
Music Tribe accepts no liability for any loss which may be suered by any
person who relies either wholly or in part upon any description, photograph,
or statement contained herein. Technical specications, appearances and
other information are subject to change without notice. All trademarks are the
property of their respective owners. Midas, Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera, Auratone
and Coolaudio are trademarks or registered trademarks of Music Tribe
Global Brands Ltd. © Music Tribe Global Brands Ltd. 2020 All rights reserved.
LIMITED WARRANTY
For the applicable warranty terms and conditions and additional information
regarding Music Tribe’s Limited Warranty, please see complete details online
at musictribe.com/warranty.
