FOOT CONTROLLER FCV100
4
Fig. 2.2: FCV100 controls (part 2)
When the battery LED indicator dims or does not light up,
you need to replace the battery. For instructions on how to
replace the battery, please refer to chapter 3 BATTERY
INSTALLATION & REPLACEMENT.
Connect your instruments via the INPUTS 1/2 using the NORM
mode. In CV mode, INPUT 2 of your FVC100 can not be used
since the control signal comes exclusively from OUTPUT 2. As
stated before, you may use INPUT 1/OUTPUT 1 in CV mode to
control the volume level of another instrument.
Fig. 2.3: FCV100 controls (part 3)
2. CONTROL ELEMENTS
