MINIFEX FEX800
DEUTSCH
FEX800
MINIFEX
Ultra-Compact 24-Bit Stereo Multi-FX Processor
s Ultra-compact 9.5 stereo multi-effects processor for studio and stage
applications
s 16 awesome FX presets in 24-bit/48 kHz resolution including reverb, delay,
chorus, flanger, phaser, rotary speaker, pitch shifter and multi-effects
s Intuitive FX Preset control with LED's indicating the selected program
s Versatile Edit and Tap/Select functions to control a wide range of FX
parameters
s Stereo Input Level control with accurate 6-digit LED Input meter for precise
level indication
s Dedicated Mix Balance and Output Level controls for perfect effects level
adjustment
s Additional footswitch connector for easy FX on/off control
s High-quality potentiometers and illuminated switches for long-term reliability
s Ultra low-noise audio operational amplifiers offer outstanding sound
performance
s All Mini Series models can be stacked on top of each other to create an ultra-
compact signal processor solution
s High-quality components and exceptionally rugged construction ensure long
life
s Conceived and designed by BEHRINGER Germany

Behringer MINIFEX FEX800 Specifications

Input Specifications

input type	¼" TS connectors, unbalanced
input impedance	30 kΩ
frequency response	10 Hz to 22 kHz, -3 dB

Output Specifications

output type	¼" TRS connectors, impedance balanced
output impedance	220 Ω
max output level	+10 dBu

System Specifications

dynamic range	96 dB, 10 Hz to 22 kHz
distortion	0.01% typ. @ 0 dBFS
crosstalk	-75 dB @ 1 kHz

Power Supply

mains connection	external power supply, 9 V~, 750 mA
mains voltage (USA/Canada)	120 V~, 60 Hz
power consumption	7.5 W

Dimensions and Weight

dimensions (H x W x D)	1.9 x 4.7 x 9.6", 48 x 120 x 242.6 mm
weight	1.46 lbs / 0.66 kg
