Behringer MINIFEX FEX800 User Manual

5
MINIFEX FEX800
DEUTSCH
TABLE OF CONTENTS
1. INTRODUCTION ......................................................................................... 5
1.1 Before you get started .......................................................................................................... 6
1.1.1 Shipment .................................................................................................................... 6
1.1.2 Initial operation ........................................................................................................... 6
1.1.3 Online registration ...................................................................................................... 6
2. CONTROL ELEMENTS AND CONNECTIONS ........................................... 7
2.1 Front panel ............................................................................................................................ 7
2.2 Rear panel ............................................................................................................................ 8
3. THE EFFECTS ............................................................................................ 9
3.1 REVERB 1 ............................................................................................................................ 9
3.2 REVERB 2 ............................................................................................................................ 9
3.3 DLY/MOD ........................................................................................................................... 10
3.4 SFX/DUAL ......................................................................................................................... 10
4. APPLICATION EXAMPLES ....................................................................... 10
4.1 The MINIFEX in the aux(iliary) path .................................................................................. 10
4.2 The MINIFEX in the insert path .......................................................................................... 11
4.3 The MINIFEX as an effects unit for instruments ................................................................ 11
5. AUDIO CONNECTIONS ............................................................................ 12
5.1 Connection with insert cables ........................................................................................... 12
5.2 Connection with 1/4" cables .............................................................................................. 13
5.3 Footswitch connection ....................................................................................................... 13
6. APPENDIX ................................................................................................. 14
6.1 List of effects and parameters ........................................................................................... 14
7. SPECIFICATIONS ..................................................................................... 15
8. OTHER MINI PRODUCTS......................................................................... 16
9. WARRANTY .............................................................................................. 17
1. INTRODUCTION
Thank you for showing your confidence in BEHRINGER products by purchasing the MINIFEX FEX800.
With the MINIFEX FEX800 you have purchased an extremely flexible yet easy-to-use multi-effects
device, which you will surely come to appreciate for its sound enhancement capabilities both on
stage and in the studio.
Our ultra-compact stereo multi-effect processor is a useful addition to any set-up: You get 16 fantastic
effects presets in 24-bit quality, including reverb, delay, chorus, flanger, phaser, rotary speaker,
pitch shifter and other multi-effects. Thanks to the intuitive FX preset control with its LEDs displaying
the currently selected program, nothing could be easier than operating the FEX800. What is more,
a variety of edit and tap/select functions allows you to modify the effect parameters extensively. A
high-precision, 6-digit LED display can be used to accurately set the stereo input level.
1. INTRODUCTION

Behringer MINIFEX FEX800 Specifications

Input Specifications

input type	¼" TS connectors, unbalanced
input impedance	30 kΩ
frequency response	10 Hz to 22 kHz, -3 dB

Output Specifications

output type	¼" TRS connectors, impedance balanced
output impedance	220 Ω
max output level	+10 dBu

System Specifications

dynamic range	96 dB, 10 Hz to 22 kHz
distortion	0.01% typ. @ 0 dBFS
crosstalk	-75 dB @ 1 kHz

Power Supply

mains connection	external power supply, 9 V~, 750 mA
mains voltage (USA/Canada)	120 V~, 60 Hz
power consumption	7.5 W

Dimensions and Weight

dimensions (H x W x D)	1.9 x 4.7 x 9.6", 48 x 120 x 242.6 mm
weight	1.46 lbs / 0.66 kg
