Behringer SPICE - Specifications

60 61Quick Start GuideSPIC E
Specications
Synthesizer Architecture
Number of voices Monophonic
Type Analog
Oscillators 2 VCO
VCF LPF 24 dB/octave
Envelopes 2 AD
Connectivity
Power switch Push button on/o
MIDI In 5-pin DIN / 16 channels
USB (MIDI) USB Micro
Headphones 3.5 mm TRS, stereo, 5 mW 32Ω
USB
Type Class compliant USB Micro
Supported operating
systems
Windows 7 or higher
Mac OS X 10.10 or higher
Oscillator Section
Controls
VCO 1 Frequency
VCO 1 Sub 1 Frequency
VCO 1 Sub 2 Frequency
VCO 1 Level
VCO 1 Sub 1 Level
VCO 1 Sub 2 Level
VCO 2 Frequency
VCO 2 Sub 1 Frequency
VCO 2 Sub 2 Frequency
VCO 2 Level
VCO 2 Sub 1 Level
VCO 2 Sub 2 Level
Buttons
Seq 1 Assign Osc 1, Sub 1, Sub 2
Seq 2 Assign Osc 2, Sub 1, Sub 2
Switches
VCO 1Waveform select
VCO 2 Waveform select
Analog Filter Section
Controls
Cuto
Resonance
Envelope Section
Controls
VCA EG Attack
VCA EG Decay
VCA EG Volume
VCF EG Attack
VCF EG Decay
VCF EG Amount
Sequencer Section
Capacity 2 sequencers, 4 steps each, assignable clock division
Control
Tempo
Sequence 1 x 4
Sequence 2 x 4
Division x 4
Buttons
Reset, EG, Next
Play/Stop, Trigger
Sequence Octave
Quantize
Division assign x 8
Patch Panel
Inputs
16 x 3.5 mm TS jack, DC coupled, normalled
VCO 1 CV, VCO 1 Sub CV, VCO 1 PWM, VCA CV, VCO 2 CV, VCO 2 Sub CV, VCO2 PWM, VCF Cuto CV
Play, Reset, Trigger, Rhythm 1 CV, Rhythm 2 CV, Rhythm 3 CV, Rhythm 4 CV, Clock
Outputs
16 x 3.5 mm TS jack, DC coupled, normalled
VCA, VCO 1, VCO 1 Sub 1, VCO 1 Sub 2, VCA EG, VCO 2, VCO 2 Sub 1, VCO 2 Sub 2
VCF EG, Seq 1, Seq 1 Clock, Seq 2, Seq 2 Clock, Clock, Trigger, Phones
Power Requirements
Mains connector 12 V DC, 1000 mA consumption
Physical
Standard operating
temperature range
5°C – 45°C (41°F – 113°F)
Dimensions (H x W x D) 45 x 164 x 321 mm (3.30 x 6.46 x 12.64")
Weight 1.48 kg (3.26 lbs)
