Specications
Processing
Input processing channels 40 stereo input channels, 8 stereo aux channels
Output processing channels 16 stereo aux buses, 8 stereo matrices, 4 stereo mains
Internal eects engines (all true stereo) 8 premium FX slots, 8 standard FX slots
Point-to-point routing matrix 500 x 502 signals
Signal processing 40-bit oating point, 48 kHz
A/D converters (8-channel, 48 kHz, 24 bits) 114 dB dynamic range*
D/A converters (stereo, 48 kHz, 24 bits) 120 dB dyanmic range*
I/O latency (console input to output) 1.0 ms
Network latency (stage box in > console > stage box out) 1.2 ms
Connectors
Midas PRO series microphone preamplier (XLR) 24
XLR balanced outputs 8
Aux inputs/outputs (¼" TRS balanced, mono) N/A
Phones output (¼" TRS, stereo) 2
Digital AES/EBU input/output (XLR) 1 / 1
AES50 ports (Klark Teknik SuperMAC, 100 Mbit/s) 3
Expansion card interface 64 x 64 channel audio input / output
StageConnect HOST(Master) I/O (12 V / 18 W power supplied, XLR, 32 channels) 1
MIDI inputs/outputs 1 / 1
GPIO on TRS, congurable 1 x 2
USB 2.0 type B device (48 x 48 ch 24-bit audio and MIDI I/O) 1
USB 2.0 type A host (audio and data, 5 VDC, 1 A) 1
Ethernet LAN ports, RJ45, 1 Gbit/s 2, internally switched
Audio over IP (AoIP) internal module socket (Dante, AES67 or SoundGrid modules optional) Up to 64 x 64 channels @ 48 kHz
IEC mains socket with power switch 1
Mic Input Characteristics (Mic Input to Analog Output)
Design Midas PRO series
THD+N (0 dB gain, 0 dBu output) <0.004%*
THD+N (+40 dB gain, 0 dBu to +20 dBu output) <0.006%*
Input impedance (unbalanced / balanced 1 kΩ / 2 kΩ
Non-clip maximum input level +21 dBu
Phantom power (switchable per input) +48 V
Equivalent input noise @ +45 dB gain (150 Ω source) -128 dBu*
CMRR @ unity gain (typical) >50 dB
CMRR @ 40 dB gain (typical) >70 dB
Input/Output Characteristics
Frequency response @ 48 kHz sample rate, 0 to -1 dB (any gain setting) 10 Hz - 20 kHz
Dynamic range, analog in to analog out (typical), XLR / aux 111 dB* / 108 dB*
A/D dynamic range, preamplier and converter (typical), XLR / aux 112 dB* / 110 dB*
D/A dynamic range, converter and output (typical), XLR / aux 118 dB* / 112 dB*
Crosstalk rejection @ 1 kHz, adjacent channels 100 dB
Output level, XLR connectors (nominal / maximum) +4 dBu / +21 dBu
Output impedance, XLR connectors (unbalanced / balanced) 75 Ω / 75 Ω
Input impedance , TRS connectors (unbalanced / balanced) n/a
Non-clip maximum input level, TRS connectors n/a
Aux output level, TRS (nominal / maximum) n/a
Aux output impedance, TRS (unbalanced / balanced) n/a
Headphone output impedance / maximum output level 500 mW @ 75 Ω / +18 dBu
Residual noise level, XLR out 1-16 connectors, unity gain -97 dBu*
Residual noise level, aux and monitor TRS out connectors n/a
Displays
Main screen 10.1" TFT LCD, 1280 x 800 px, capacitive touch
Main screen swivel, continuous adjustment 15°- 60°
4-channel group LCD screen with RGB color strip per channel N/A
Channel editing screen N/A
Button assignment screen 2.4" TFT LCD, 240 x 320 px
Main stereo meter 18 segment (-60 dB to clip)
Controls
100 mm motor faders 12 + 1
Touch-sensitive rotary controls 7 + 3
Custom Controls
Fully assignable rotary controls N/A
Fully assignable backlit buttons 16
Variable rotary controls / buttons N/A
Power
Switch-mode power supply Auto-ranging 100-240 VAC (50/60 Hz)
Power consumption 130 W
Physical
Standard operating temperature range 5°C – 45°C (41°F – 113°F)
Dimensions (H x W x D) 225 x 453 x 574 mm (8.9 x 17.8 x 22.6")
Weight 15.4 kg (34 lbs)
*A-weighted noise and dynamic range figures
