12
Channel Section Global View: LCD displays show channel numbers and names in banks of 8
SOLO
MUTE
SELECT
functions pertaining to the selected block of 8 channels
Faders fader levels pertaining to the selected block of 8 channels
Meters channel input meters pertaining to the selected block of 8 channels
Encoder
Assign
turn: push: push + turn: push + REC: REC button:
all channels on selected bank
Global View
(default)
panorama pan-center — — —
TRACK gain/trim — source select
48 V phantom
“P” indicates
48 V ON
Select
Analog In or
USB Return*
PAN/SURROUND panorama pan-center — —
Channel to
Main LR on/o
FLIP
(Sends-on Fader)
panorama
when sending
to stereo bus
pan-center
when sending
to stereo bus
Channel Send
Mode: Input,
Pre/PostEQ,
Pre/Post Fdr,
SubGroup
—
Channel ON,
when bus is
in SubGroup
mode
for selected channel
EQ (Channel)
page 1/2
1: select chan.
2: page select
3: LowCut freq.
4: —
5: Gain1
6: Gain2
7: Gain3
8: Gain4
—
1: —
2: page select
3: LowCut freq.
4: —
5: Freq1
6: Freq2
7: Freq3
8: Freq4
—
1: —
2: EQ on/o
3: LowCut
on/o
4: —
5: —
6: —
7: —
8: —
EQ (Channel)
page 2/2
1: select chan.
2: page select
3: LowCut freq.
4: —
5: Q1
6: Q2
7: Q3
8: Q4"
—
1: —
2: —
3: —
4: —
5: Band Type1
6: Band Type2
7: Band Type3
8: Band Type4
—
1: —
2: EQ on/o
3: LowCut
on/o
4: —
5: —
6: —
7: —
8: —
EQ (Bus)
page 1/2
1: select chan.
2: page select
3: Gain1
4: Gain2
5: Gain3
6: Gain4
7: Gain5
8: Gain6
—
1: —
2: Bus-EQ
mode
3: Freq1
4: Freq2
5: Freq3
6: Freq4
7: Freq5
8: Freq6
—
1: —
2: EQ on/o
3: —
4: —
5: —
6: —
7: —
8: —
