X-TOUCH Remote Control of X AIR Mixers
With the release of X-TOUCH rmware version 1.15, the X-TOUCH is able to remotely control the X AIR
series mixers: XR12, XR16, X18, and XR18. The connection between the X-TOUCH and the mixer can be
made via Ethernet connection or MIDI in and out connections. This document shows how to make the
connections, and how to use the X-TOUCH in Xctl mode, Xctl + MC mode, and Xctl + HUI mode.
Operating Modes: Display Network MIDI USB Footswitch/Pedal
Mackie Control Emulation MC
999 9
Mackie HUI Emulation HUI
999 9
X AIR mixer control Xctl X AIR X AIR — —
X AIR and MCU control* Xctl/MC X AIR X AIR
99
X AIR and HUI control* XctlHUI X AIR X AIR
99
9
– used for DAW control surface
* – toggle between X AIR and DAW control with “SMPTE/BEATS” button
Preparing a Connection Between X AIR Mixer and X-TOUCH Control Surface
Steps: Preparation
1 a Make sure your X AIR Mixer is updated to rmware 1.12 or higher
b
If necessary, go to your X AIR Mixer’s product page on behringer.com and download the most recent
rmware le to your PC
c Connect the X AIR EDIT application on your PC with your X AIR Mixer
d Open the Setup/Connection page and upload the new rmware to your mixer
2 a
Make sure your X-TOUCH is updated to rmware 1.15 or higher. The current rmware is brie y displayed
above “BARS” when starting
b
If necessary, go to the X-TOUCH product page on behringer.com and download the most recent
rmware update le to your PC
c Follow the instructions in the Readme.txt le contained inside the download zip le
3 a
Connect the X-TOUCH and X AIR Mixer using a standard Ethernet LAN cable, or alternatively using
2 MIDI cables (when “Ifc Mode” is MIDI)
b Move the small slider switch on the X AIR Mixer to the “Ethernet” position and power the mixer up
