Page #2 background image
2 XENYX 1002 Technical Specifications
XENYX 1002
Premium 10-Input 2-Bus Mixer with XENYX Mic Preamps and British EQs
Premium, ultra-low noise, high headroom analog mixer
2 state-of-the-art XENYX Mic Preamps comparable to stand-alone boutique preamps
Neo-classic “British” 3-band EQs for warm and musical sound
1 post fader FX send per channel for external FX devices
Main mix outputs plus separate control room, phones and stereo CD/tape outputs
CD/tape inputs assignable to main mix or control room/phones outputs
FX to control room function helps to monitor eect signal via headphones and control room outputs
Long-wearing 60-mm logarithmic-taper master fader and sealed rotary controls
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Mono Inputs
Microphone Inputs (XENYX Mic Preamp)
Type XLR connector, electronically
balanced, discrete input circuit
Mic E.I.N.
1
(20 Hz - 20 kHz)
@ 0Ω source resistance -134dB / 135.7dB A-weighted
@ 50Ω source resistance -131dB / 133.3dB A-weighted
@ 150Ω source resistance -129dB / 130.5dB A-weighted
Frequency Response
<10Hz - 150kHz -1dB
<10Hz - 200kHz -3dB
Gain range +10dB to +60dB
Max. input level +12dBu @ +10dB GAIN
Impedance approx. 2.6kΩ balanced
Signal-to-noise ratio 110dB / 112dB A-weighted
(0dBu In @ +22dB GAIN)
Distortion (THD + N) 0.005% / 0.004% A-weighted
Line Input
Type ¼" TRS jack, electronically balanced
Impedance approx. 20kΩ balanced,
approx. 10kΩ unbalanced
Gain range -10dB to +40dB
Max. input level +22dBu @ 0dB GAIN
Fade-Out Attenuation
2
(Crosstalk Attenuation)
Main fader closed 90dB
Channel muted 89.5dB
Channel fader muted 89dB
Frequency Response (Mic In Main Out)
<10Hz - 90kHz +0dB / -1dB
<10Hz - 160kHz +0dB / -3dB
Stereo Inputs
Type ¼" TRS jack, electronically balanced
Impedance approx. 20k
Max. input level +22dBu
Equalizer
EQ Mono Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
EQ Stereo Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
Specications

Other manuals for Behringer XENYX 1002

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Behringer XENYX 1002 and is the answer not in the manual?

Behringer XENYX 1002 Specifications

General IconGeneral
Frequency range10 - 200000 Hz
Channels quantity10 channels
Digital sound processing- bit
Line Signal-to-Noise Ratio (SNR)110 dB
Total Harmonic Distortion (THD)0.005 %
XLR out1
Microphone inYes
DJ mixer-
Product colorBlack
Power consumption (typical)13 W
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width189 mm
Height37 mm
Weight1600 g
