Page #2 background imageLoading...
Page #2 background image
2 XENYX 502 Technical Specifications
XENYX 502
Premium 5-Input 2-Bus Mixer with Xenyx Mic Preamps and British EQs
Premium ultra-low noise, high headroom analog mixer
State-of-the-art, phantom powered XENYX Mic Preamp comparable to stand-alone boutique preamps
Neo-classic “British” 2-band EQ for warm and musical sound
Main mix, stereo CD/tape plus separate headphone outputs
CD/tape inputs assignable to headphone output or main mix outputs
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Mono Inputs
Microphone Inputs (XENYX Mic preamp)
Type XLR connector, electronically
balanced, discrete input circuit
Mic E.I.N.
1
(20 Hz - 20 kHz)
@ 0Ω source resistance -134dB / 135.7dB A-weighted
@ 50Ω source resistance -131dB / 133.3dB A-weighted
@ 150Ω source resistance -129dB / 130.5dB A-weighted
Frequency Response
<10Hz - 150kHz -1dB
<10Hz - 200kHz -3dB
Gain range +10dB to +60dB
Max. input level +12dBu @ +10dB GAIN
Impedance approx. 2.6kΩ balanced
Signal-to-noise ratio 110dB / 112dB A-weighted
(0dBu In @ +22dB GAIN)
Distortion (THD + N) 0.005% / 0.004% A-weighted
Line Input
Type ¼" TRS jack, electronically balanced
Impedance approx. 20kΩ balanced,
approx. 10kΩ unbalanced
Gain range -10dB to +40dB
Max. input level +22dBu @ 0dB GAIN
Fade-Out Attenuation
2
(Crosstalk Attenuation)
Main fader closed 90dB
Channel muted 89.5dB
Channel fader muted 89dB
Frequency Response (Mic In Main Out)
<10Hz - 90kHz +0dB / -1dB
<10Hz - 160kHz +0dB / -3dB
Stereo Inputs
Type ¼" TRS jack, electronically balanced
Impedance approx. 20k
Max. input level +22dBu
Equalizer
EQ Mono Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
EQ Stereo Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
Specications

Other manuals for Behringer Xenyx 502

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Behringer Xenyx 502 and is the answer not in the manual?

Behringer Xenyx 502 Specifications

General IconGeneral
Inputs5
TypeAnalog
Channels5
Inputs - Mic Preamps1 x XLR
Outputs - Main2 x 1/4"
Headphone Output1 x 1/4"
EQ2-band EQ
Phantom PowerYes
Headphones Output1
Weight1.2 lbs
Outputs - Other2 x RCA
Frequency Response10 Hz
THD<0.1%
Signal-to-Noise Ratio110dB (A-weighted)
Power SupplyExternal power supply
Dimensions1.85 x 5.9 x 7.0" / 47 x 150 x 177 mm
