Behringer Xenyx UFX1604 User Manual

20 XENYX UFX1604 Quick Start Guide 21
Gain Setting
(EN) Step 4: Gain Setting
Press the Channel 1 SOLO button.
Pressthe MODE button under the
VUMETER in the main section to allow
the METER to operate in PFL (pre-fader listen) mode.
Sing, Speak or play at a normal level
through the microphone or instrument
connected to Channel 1.
While singing or playing, turn Channel 1’s
GAIN knob. The VU METER will display the
signal level. Set the GAIN so the loudest
peaks reach 0 on the VU METER. Press the Channel 1
SOLO button again.
Repeat steps 1-3 for any other channels
that will be used.
Dual Multi-FX Processors
(EN) Step 5:
DualMulti-FX
Processors
Your mixer has two built-in eects processors.
Follow these steps to add one or two eects to one
or more channels.
Turn the FX A or FX B knob up halfway on
each channel you would like to add an
eect to.
Turn the FX SEND and FX RETURN knobs
to “0”. You may adjust them later.
Make sure the FX ON button is pushedin.
Scroll through the eects by turning the
FX A knob (same for FX B).
Adjust the intensity of the eect by
turning the EDIT knob.
If using presets 1-8, 13-14 or 16, pressthe
TAP/SELECT button to toggle between
two dierent values
(light o/on) for the second parameter.
To adjust the delay time of presets 9 and 15, hitthe
TAP/SELECT button several times in the tempo of the
music piece. Similarly, hit the TAP/SELECT button
several times to adjust the modulation speed of
presets 10-12. The button will start ashing in the
corresponding tempo.
Readjust each channel’s FX knobs to
make sure the right amount of FX A orFX
B is added.

Behringer Xenyx UFX1604 Specifications

General

Brand	Behringer
Model	Xenyx UFX1604
Category	Music Mixer
Language	English
