Installation
2.2.1 Mode Switches
All mode switches must be in OFF position during operator panel use.
Themodeswitchesshouldnotbetouchedunlessbyqualifiedpersonnel.
1
24V DC
CF CARD
COM 1 RS422 RS485
COM 2 RS232
10/100
EXPANSION
BUSY
MODE
1 2 3 4
ON DIP
MODE
1 2 3 4
ON DIP
2.2.2 Connections to the Controller
For information about the cablestobeusedwhenconnecting
the operator panel to
the controller, please refer to the help file for the
driver in question.
2.2.3 Other Connections and Peripherals
Cables, peripheral equipment and accessorie
smustbesuitablefortheapplication
and its environment. For further details or r
ecommendations, please refer to the
supplier.
Caution:
When using a compact flash card, do not remove the card when the busy indicator is
illuminated.
Beijer Electronics, MAEN774E
10
