Technical Data
3TechnicalData
Parameter EXTER T100
Frontpanel,WxHxD 302x228x6mm
Mountingdepth 58 mm (158 mm including clearance)
Front panel seal IP 66
Rear panel seal IP 20
Keyboard
material/Front
panel
Touch screen: Polyester on glass,1 million finger touch
operations. Overlay: AutotexF157 or F207*.
Reverse side
material
Powder-coated aluminum
Weight 2.1 kg
Serialport
RS422/RS485
25-pin D-sub contact,chassis-mounted female with
standard locking screws 4-40 UNC
SerialportRS232C 9-pin D-sub contact, male with standard locking screws 4-40
UNC
Flashmemory for
application
12 MB (incl. fonts)
Ethernet ShieldedRJ 45
USB Host type A (USB 1.1), max output current500 mA
DevicetypeB(USB1.1)
CF-slot Compactflash, type Iand II
Realtime clock ±20 PPM +error because ofambient temperature. Total
maximumerror: 1 minute/monthat 25°C.
Tempera ture c oe fficient: -0.034±0.006 ppm/°C
2
Real time clock
battery
CR2450 (UL and cUL: Sanyo or Panasonic)
Minimumlifetime: 3 years
Power consumption
at rated v oltage
Normal: 0.5 A
Maximum: 1.0 A
Display TFT-LCD, 800 x 600 pixels, 64K colors.
LED backlightlifetimeat the ambient temperature of
+25 °C: >50,000 h.
Activearea of
display,W x H
211.2 x 158.4 mm
Fuse Internal DC fuse, 3.1 5 AT, 5 x 20 mm
Power supply +24 V DC (20 - 30V DC). Power supply connector.
CE: The powersupply must conform withthe requirements
accordingto IEC 60950andIEC 61558-2-4.
UL and cUL: The powersupply must conform with the
requirements for class II power supplies.
Ambient
temperature
Vertical installation: 0° to +50 °C
Horizontal installation: 0 ° t o +40 °C
Storagetemperature -20° to +70°C
Beijer Electronics, MAEN774E
11
