4. Technical Data
Parameter X2 base 7 v2 HP
Front panel, W×H×D 202x152x37 mm
Cutout dimensions, W×H 186x136 (+/-1) mm
Mounting depth 32 mm (132 mm including clearance)
Mounting Switchboard installation
Front panel seal IP 65 (Non-UL certified)
Rear panel seal IP 20 (Non-UL certified)
Touch screen material Polyester on glass, ITO film, resistive
Frame overlay Autoflex EBA 250L
Touch screen operations 1 million finger touch operations
Reverse side material Plastic
Frame material Plastic
Weight 0.58 kg
CPU TI Sitara AM335x Single Core 1GHz, (TI AM3352BZCZ100)
Serial port COM A Standard DSUB (9-pin, female). 1x RS-232 RX/TX with RTS/CTS,
1x RS-422 or 2x RS-485
Serial port COM B Standard DSUB (9-pin, female). 1x RS-232 RX/TX with RTS/CTS,
1x RS-422 or 1x RS-485
Serial port COM C 3 pin screw connector 1x RS-485
Ethernet LAN A 10/100 Mbit/s. Shielded RJ 45
Ethernet LAN B 10/100 Mbit/s. Shielded RJ 45
USB-A 1 × USB Host 2.0, max output 500 mA
USB-B 1 × USB Host 2.0, max output 500 mA
External storage media 1 × μSD card
Flash memory (application
memory)
2 GB
Memory RAM 512 MB (DDR3)
NVRAM 16 kB
LED N/A
Real time clock Yes
Battery Lithium battery type CR 2032, exchangeable
Power consumption at
rated voltage
7.2 W
Fuse Internal DC fuse, 3 AT, SMD
Power supply +24 VDC (18-32 V DC) CE: The power supply must conform
with the requirements according to EN/IEC 60950 and EN/IEC
61558-2-4. UL and cUL: The power supply must conform with
the requirements for class 2 power supplies. Maximum Current
1.32 A. Maximum Power 23.8 W.
Display 7.0” TFT-LCD with LED backlight. 800x480 pixels, 16M colors
Technical Data
2023-09 14 Beijer Electronics, MAEN330

Beijer Electronics X2 base 7 v2 HP Specifications

General

Brand	Beijer Electronics
Model	X2 base 7 v2 HP
Category	Touchscreen
Language	English
