3522.5-0000010 РЭ
20
Table 1.1 continued
Parameter title
(characteristics)
Parameter value for the tractor
“BELARUS-3522.5”
8 Distribution of operating weight on ax-
les, kg:
а) on front 4750±50
b) on rear 7100±110
9 Permitted load on axles, kN:
a) on front 80
b) on rear 112
10 Max weight of the trailer, kg
a) without brakes 5800
b) with independent brake 5800
c) with overrunning brake 25000
d) equipped with a brake system (trailer
brakes are interconnected with tractor
brakes)
40000
11 Clearance, mm, not less than:
а) road under drawbar hitch 355
b) agrotechnical under rear wheel as-
semblies 550
12 Track dimensions, mm:
а) for front wheels
2000±20, 2150±20
b) for rear wheels
from 2020±20 to 2140±20 and from 2316±20 to
2576±20
13 Least radius of turning circle, m 6,5
14 Tractor base, mm
3000±20
15 Crossed hindrances:
а) angle of climb without trailer, not less
than
20º
b) angle of climb without trailer, not less
than
12º
c) max fordable depth, m
0,8
16 Overall dimensions, mm:
а) length with front and rear lift linkages
in transport position
6250±50
b) width on rear wheel tyres
- on tyres 650/75R42
2550±20
c) height to the top of cab
3350±50
17 Tyres:
а) front wheels 600/65R34
5)
b) rear wheels 710/70R42
6)
18 Electrical equipment under GOST 3940:
а) rated supply voltage in on-board
power system, V 12
b) rated ignition voltage, V
12
